UVP UV, White & Blue Light Transilluminators

  • Filter sizes from 15 cm x 15 cm up to 25 cm x 26 cm or 20 cm x 40 cm

  • Exceeding uniform illumination

  • High-grade filter glass for low background

  • Wide choice of standard and high-performance models



Product Details

UV transilluminators for UV fluorescent stains

The UV transilluminators feature a uniform and bright illumination. The exclusive application of high-grade filter glass provides for excellent documentation results with lowest background signal. The great illumination uniformity allows the reliable quantification of electrophoretically separated fluorescent samples.

The UVP Transilluminators are equipped with an ultraviolet blocking cover to shield the user from UV radiation. The base is painted with high-quality, scratch-resistant powder coat. Models include a stainless steel top assembly or powder coat paint.

UVP Transilluminators
The compact models of the UVP Transilluminators include the economical single intensity and variable intensity transilluminators which are equipped with 8-watt, 302 nm UV tubes.

The variable intensity models feature:

  • High setting allows UV excitation of fluorophores on gels for routine photography. Also excites gels with low sample concentration.
  • The medium intensity is excellent for viewing and quick singleband excision.
  • Low setting is used for positioning and preparation of the gel, excising multiple bands, and focusing for photography.

For users who prefer the choice between 302 nm UV and 365 nm UV the benchUV ML models are suited. These models come with single intensity setting and 8-watt UV bulbs of 302 nm and 365 nm. Available filter sizes are 20 cm x 20 cm or 21 cm x 26 cm.

Transilluminators with extraordinary uniform illumination
The UVP FirstLightTransilluminator represent a unique highly uniform 302 nm UV excitation source for quantitative fluorescent imaging in a wide range of applications.

  • Produces < 5% coefficient of variance (CV) across the full filter area
  • Exceptionally uniform, edge-to-edge illumination
  • Accurate gel to gel comparison
  • Uniformity ensures consistent illumination over the imaging surface resulting in high quality images
  • Applications range from DNA and protein gel documentation and analysis

The transilluminator achieves accurate and reproducible RNA, DNA and protein results. The illuminator emits 302 nm UV excitation and combined with a patented phosphor coating configuration generates exceptionally uniform UV illumination over each band and lane. Multiple gels may be placed on the surface with assurance of uniformity for each gel.

High performance UV transilluminators
All high performance UVP Transilluminator include the exclusive 25-watt ultraviolet tubes and provide a total of 100 watts of brilliant UV illumination.

  • Deliver high UV output and intensity, no light flicker, fast lamp start-up and reduced electrical consumption
  • Stainless steel frame enables easy cleaning
  • The back-lit UV illumination is further enhanced with long-life filter and uniformity screen
  • UV blocking cover, included with each transilluminator, is adjustable for access to the filter surface

Blue light transilluminators for fluorescent stains
Blue light transilluminators are a quite interesting alternative to UV transilluminators as there is no risk of sample damage during illumination. This is important when samples shall be processed furthermore after gel documentation. Users also benefit from it as there is no risk of UV exposure. Blue light excitation is applicable for fluorescent dyes for nucleic acid or protein stains with excitation wavelengths around 470 nm. Examples for compatible stains are:
SYBR Green, GelGreen, SYBR Safe, SYBR Gold or SYPRO Ruby and GFP stains.

The blue light illuminator UVP Visi-Blue Transilluminatoris available as compact 8-watt model and in its size similar to the benchtop models UV transilluminators. The amber protective cover blocks blue light transmission, allows visualization of most samples above 500 nm.

UV-to-blue converter plates
Alternative to a blue light transilluminator a converter plate can be applied on top of a UV transilluminator to convert UV light to blue light. Three different sizes of the Visi-Blue converter plate are available. In combination with a camera system an amber camera filter has to be applied.

White/UV transilluminator
The UVP Visi-White transilluminator is also available as dual use version: UV table and white light table. UVP UV/White Transilluminator TMW-20 features a 20 cm x 20 cm filter size for UV fluorescent samples and additional a 20 cm x 20 cm filter size for white light transillumination. The white light table can be used for the documentation of all visible colored samples like silver or Coomassie Blue stained gels as well as for radiographs. This transilluminator can not be integrated into a GelStudio or ChemStudio darkhood due to its geometry.

UV to white light converter plates
Alternatively to the use of a white light table a converter plate can be applied at the top of a UV transilluminator. The converter plate converts the UV light to visible light and thus economically extents the application scope of all UV table models to the visualisation of colored dyes.

White light table UVP Visi-White Transilluminator
For documentation of only visible colored samples without the need for any UV light the white light transilluminator UVP Visi-White Transilluminator TW-26 is the table of choice. It comes with a 21 cm x 26 cm filter size. The exceeding uniform illumination provides for bright sample images.

Technical Data

Features

Benefit

Compact size with small footprint

Saves bench space and is compatible with GelStudio gel documentation darkhoods

Stainless steel filter frame

Robust and easy to clean for daily routine

Freely adjustable UV protection shield

User UV protection during handling the gel

Lamp control with electronic high-frequency operating
system

Flicker-free illumination and
extended lamp durability

Quiet, temperature controlled ventilation

Samples are protected from heating

For compatibility of transilluminators with Analytik Jena imaging systems please check this table:


GelStudio SA2,
ChemStudio,
ChemStudio SA2,
ChemStudio PLUS

Dimensions
(height incl.
protection shield)
H x W x D, cm

Transilluminator version

UVP Transilluminator
with 8 W tubes

              +

13.7 x 35.6 x 27.9

UVP FirstLight® Transilluminator

              +

13.7 x 35.6 x 27.9

UVP Transilluminator high performance with
25 W tubes

              -

14.3 x 48.6 x 33.7

UVP Visi-Blue Transilluminator

              +

13.7 x 35.6 x 27.9

UVP UV/White Transilluminator

               -

14.3 x 48.6 x 33.7

UVP Visi-White Transilluminator

              +

10.8 x 33.7 x 24.1

Order Information

Order number  Description
UV transilluminators without intensity setting, 302 nm UV

230 V
849-20015-0

110 - 115 V
849-20015-4

UVP Transilluminator M-15
filter size 15 cm x 15 cm, 8 W 302 nm UV, UV protection shield

230 V
849-20016-0

110 - 115 V
849-20016-4

UVP Transilluminator M-20,
filter size 20 cm x 20 cm, 8 W 302 nm UV, UV protection shield
230 V
849-20017-0

110 - 115 V
849-20017-4
UVP Transilluminator M-26
filter size 21 cm x 26 cm, 8 W 302 nm UV, UV protection shield
UV transilluminators with variable intensity setting, 302 nm UV

230 V
849-20018-0

110 - 115 V
849-20018-4

UVP Transilluminator M-15V
filter size 15 cm x 15 cm, 8 W 302 nm UV, high/medium/low intensity setting,
UV protection shield
230 V
849-20019-0

110 - 115 V
849-20019-4
UVP Transilluminator M-20V
filter size 20 cm x 20 cm, 8 W 302 nm UV, high/medium/low intensity setting,
UV protection shield
230 V
849-20020-0

110 - 115 V
849-20020-4
UVP Transilluminator M-26V
filter size 21 cm x 26 cm, 8 W 302 nm UV, high/medium/low intensity setting,
UV protection shield
230 V
849-20021-0

110 - 115 V
849-20021-4
UVP Transilluminator M-26XV
filter size 25 cm x 26 cm, 8 W 302 nm UV, high/medium/low intensity setting,
UV protection shield
UV transilluminators without intensity setting, 2 UV wavelengths: 302 nm, 365 nm
230 V
849-20011-0

110 - 115 V
849-20011-4
UVP 2UV Transilluminator LM-20
filter size 20 cm x 20 cm, 8 W 302/365 nm UV, UV protection shield

230 V
849-20012-0

110 - 115 V
849-20012-4

UVP 2UV Transilluminator LM-26
filter size 21 cm x 26 cm, 8 W 302/365 nm UV, UV protection shield
UV transilluminators without intensity setting, 3 UV wavelengths: 245 nm, 302 nm, 365 nm
230 V
849-20013-0

110 - 115 V
849-20013-4
UVP 3UV Transilluminator LMS-20
filter size 20 cm x 20 cm, 8 W 254/302/365 nm UV, UV protection shield
230 V
849-20014-0

110 - 115 V
849-20014-4
UVP 3UV Transilluminator LMS-26
filter size 21 cm x 26 cm, 8 W 254/302/365 nm UV, UV protection shield
Uniform illuminated FirstLight® Transilluminator UV transilluminators, without intensity setting, 302 nm UV
230 V
849-20001-0

110 - 115 V
849-20001-4
UVP FirstLight® Transilluminator FI-20 filter size 20 cm x 20 cm, 302 nm UV grid, UV protection shield
230 V
849-20003-0

110 - 115 V
849-20003-4
UVP FirstLight® Transilluminator FI-26X filter size 25 cm x 26 cm, 302 nm UV grid, UV protection shield
High-Performance UV transilluminators with variable intensity setting, 302 nm or 365 nm UV
230 V
849-20035-0

110 - 115 V
849-20035-4
UVP Transilluminator PL TFM-20V
filter size 20 cm x 20 cm, 25 W 302 nm UV, high/medium/low intensity setting, UV protection shield
230 V
849-20037-0

110 - 115 V
849-20037-4
UVP Transilluminator PL TFM-30V
filter size 25 cm x 30 cm, 25 W 302 nm UV, high/medium/low intensity setting, UV protection shield
230 V
849-20034-0

110 - 115 V
849-20034-4
UVP Transilluminator PL TFL-40V
filter size 20 cm x 40 cm, 25 W 365 nm UV, high/medium/low intensity setting, UV protection shield
Blue light transilluminator, 460 - 470 nm with variable intensity setting
849-20070-0UVP Visi-Blue Transilluminator VB-26
filter size 21 cm x 26 cm, 8 W 460 - 470 nm, high/medium/low intensity setting, amber lid, incl. camera emission filter 50 x 50 mm.
UV (302 nm)/white light transilluminator, without intensity setting
230 V
849-20052-0

110 - 115 V
849-20052-4
UVP UV/White Transilluminator TMW-20
filter size 20 cm x 20 cm for UV and 20 cm x 20 cm for white light, 8 W 302 nm UV,
8 W white light, UV protection shield
White light transilluminator, without intensity setting
230 V
849-20060-0

100 - 115 V
849-20060-4

UVP Visi-White Transilluminator TW-26
filter size 21 cm x 26 cm, 8 W white light

Converter plates
849-20510-0UVP Visi-White Plate, 21 cm x 26 cm filter size
849-20511-0UVP Visi-White Plate, 25 cm x 26 cm filter size
849-20512-0UVP Visi-White Plate, 20 cm x 40 cm filter size
849-20520-0UVP Visi-Blue Plate, 21 cm x 26 cm filter size, 460 nm - 470 nm*
849-20521-0UVP Visi-Blue Plate, 25 cm x 26 cm filter size, 460 nm - 470 nm*
849-20522-0UVP Visi-Blue Plate, 20 cm x 40 cm filter size, 460 nm - 470 nm*
849-20523-0Converter plate UV302-to-UV365, 25 cm x 26 cm filter size
* Includes amber 50 mm square camera filter, compatible with UVsolo, GelStudio SA2 and ChemStudio Series.
Previous description:
benchUV FirstLight20, benchUV FirstLight26, benchUV 20ML, benchUV 26ML, benchUV 20SML, benchUV 20SML, benchUV 15, benchUV 26, benchUV 20i, benchUV 26i, benchUV 26Xi, benchUV 40Lhi, benchUV 20hi, benchUV 30hi, benchUV WL20, benchWL 26, benchBL 26, UV/White Converter, Blue (480 nm) Converter
